Golf Simulator Cabin 7.0×4.0m, 70mm
Golf Simulator Cabin 7.0x4.0m is a log cabin for a golf simulator room with an apex roof, supplied as a building kit.
Supplied to dealers, distributors and private-label brands; for private buyers the supply route is confirmed project by project.
Technical data sheet
Specification recorded for Golf Simulator Cabin 7.0×4.0m, 70mm. Dimensions are the building's external dimensions. A row appears only where a figure is recorded for this model.
| Building | |
|---|---|
| External dimensions | 4.34 x 7.34 m |
| External footprint area | 31.9 m² |
| Eaves height | 240.5 cm |
| Ridge height | 364 cm |
| Storeys | 1 |
| Base | External footprint 4.34 x 7.34 m. Base type and size are confirmed for the specific model and site. |
| Structure | |
| Wall profile | 70 x 130 mm as standard |
| Other wall options | A solid log model can be made in any of the 28, 34, 44, 58 and 70 mm profiles; the profile is confirmed in the written quotation. |
| Construction | Interlocking solid log walls |
| Timber | Northern European timber |
| Storm brace and anchor set | Included |
| Floor | |
| Floor bearers | 40 x 60 mm, impregnated as standard |
| Floor boards | 28 mm |
| Roof | |
| Roof form | Apex |
| Roof boards | 19 mm boards |
| Roof purlins | 5 purlins, 70 x 130 mm |
| Doors and windows | |
| Doors | Double, 68mm, 1400x2030mm, two-thirds glazed |
| Windows | 2x 700x1510mm |
| Scope of these figures | |
| Insulation | Eurodita supplies the timber structure prepared for insulation where required, not the insulation material. |
| Performance | These dimensions establish no thermal, fire, structural or certification performance. |
Add-ons & Customisation
Options for this model (branding, wall thickness, openings, insulation preparation, partitions, veranda) are listed on What is in a Eurodita kit and confirmed per order.
Need this in a different size?
This model is supplied as a 4.34 x 7.34 m footprint, 70 mm wall profile. If you need a different size or layout, send a drawing. Eurodita will confirm whether the bespoke route and the factory scope fit the project. Partner branding is agreed per order.
- 1 Send a drawing A hand sketch can start the review. Mark known window and door positions, wall thickness and heights; Eurodita confirms any missing technical inputs.
- 2 Confirm the quotation scope If the enquiry fits, pricing and any CAD/3D or technical material are prepared to the agreed scope.
- 3 Review the agreed scope Revisions follow the quotation and project scope until written sign-off.
CAD/3D quotation material is prepared to the qualified project scope. Availability and timing are confirmed during qualification. Partner branding is applied where agreed; required manufacturer, legal and traceability information is retained.
Send a bespoke briefDimensions, wall thickness and opening positions are confirmed per project at quote stage. Bespoke production timing is confirmed at quotation stage. See published projects for built examples with dimensions and drawings, or review the rest of the golf simulator cabins range.
About This Golf Simulator Cabin 7.0×4.0m, 70mm
The model
Golf Simulator Cabin 7.0x4.0m is a log cabin for a golf simulator room with an apex roof, supplied as a building kit. It measures 4.34 x 7.34 m externally, an external footprint of 31.9 m². The ridge height is 364 cm and the eaves height 240.5 cm. It has one storey. It is listed with the golf simulator cabins.
Walls
The wall logs are solid, of the 70 x 130 mm profile: each log is 70 mm thick and 130 mm high, with tongue and groove along its length and interlocking corner joints. Wall logs are supplied untreated by default. This model can also be made with 28, 34, 44 or 58 mm wall logs, and the profile is confirmed in the written quotation. The profiles are set out on wall thickness and glulam profiles.
Floor and roof
The floor is 28 mm floorboards on impregnated floor bearers of 40 x 60 mm. The roof is boarded with 19 mm boards on five purlins of 70 x 130 mm. A storm brace and anchor set is included.
Doors and windows
The model has a double door of 1400 x 2030 mm in a 68 mm profile, two-thirds glazed. It has two windows of 700 x 1510 mm.
Planning in England
In England a garden building that is incidental to the enjoyment of a house can be permitted development under Class E of Part 1 of Schedule 2 to the Town and Country Planning (General Permitted Development) (England) Order 2015 (S.I. 2015/596, revised text of legislation.gov.uk, read on 29 September 2026). Among its conditions: a single storey, eaves no higher than 2.5 metres, and a height of no more than 4 metres for a building with a dual-pitched roof, or 2.5 metres for a building within 2 metres of the boundary. This model has an apex roof, which is a dual-pitched roof, an eaves height of 240.5 cm and a ridge height of 364 cm: it is within the 2.5 metres of the eaves and the 4 metres of a dual-pitched roof, and above the 2.5 metres that apply within 2 metres of a boundary. The other conditions of Class E, and whether it applies to a site at all, are confirmed with the local planning authority.
What can be changed
Size, layout and the positions of doors and windows can be changed for an order. Send a sketch or a drawing: the written quotation is prepared in the Eurodita design and estimator system, with 2D drawings and a 3D visualisation. Cable channels are machined in the wall logs where the order specifies them. More on bespoke orders.
Supply
The kit is quoted in writing and supplied EXW from the Eurodita factory. Installation and how it is organised is agreed per project; foundations, utilities and approvals stay with the local team of the buyer. What the kit holds is set out on What is in a Eurodita kit.
