Double Log Garage 6×6, Pent, 44mm
Technical data sheet
Specification recorded for Double Log Garage 6x6, Pent, 44mm. Dimensions are the building's external dimensions. A row appears only where a figure is recorded for this model.
| Building | |
|---|---|
| External dimensions | 6 x 6 m |
| External footprint area | 36 m² |
| Eaves height | 221 cm |
| Ridge height | 260 cm |
| Base | External footprint 6 x 6 m. Base type and size are confirmed for the specific model and site. |
| Structure | |
| Wall profile | 44 x 130 mm as standard |
| Other wall options | Other approved solid wall profiles can be specified to suit the project and budget. |
| Construction | Interlocking tongue and groove joints |
| Timber | Northern European timber |
| Storm brace and anchor set | Included |
| Roof | |
| Roof type | Pent |
| Roof boards | 19 mm tongue and groove boards |
| Doors and windows | |
| Doors | Double-Glazed Timber Joinery, Standard Profile |
| Windows | Double-Glazed Timber Joinery, Standard Profile |
| Scope of these figures | |
| Insulation | Eurodita supplies the timber structure prepared for insulation where required, not the insulation material. |
| Performance | These dimensions establish no thermal, fire, structural or certification performance. |
Add-ons & Customisation
Options for this model (branding, wall thickness, openings, insulation preparation, partitions, veranda) are listed on What is in a Eurodita kit and confirmed per order.
Need this in a different size?
This model is supplied as a 6 x 6 m footprint, 44 mm wall profile. If your customer needs a different layout, send a drawing. Eurodita will confirm whether the qualified bespoke route and factory scope fit the exact project. Partner branding is agreed per order.
- 1 Send a drawing A hand sketch can start the review. Mark known window and door positions, wall thickness and heights; Eurodita confirms any missing technical inputs.
- 2 Confirm the quotation scope If the enquiry fits, pricing and any CAD/3D or technical material are prepared to the agreed scope.
- 3 Review the agreed scope Revisions follow the quotation and project scope until written sign-off.
CAD/3D quotation material is prepared to the qualified project scope. Availability and timing are confirmed during qualification. Partner branding is applied where agreed; required manufacturer, legal and traceability information is retained.
Send a bespoke briefDimensions, wall thickness and opening positions are confirmed per project at quote stage. Bespoke production timing is confirmed at quotation stage. See published projects for built examples with dimensions and drawings, or review the rest of the garages & carports range.
About This Double Log Garage 6×6, Pent, 44mm
Product Overview
Contractors and developers seeking reliable equipment housing will find the Double Log Garage 6x6 delivers practical storage for construction vehicles and machinery. This pent-roof design incorporates 44mm Northern European timber walls with professional-grade double glazing. The 6x6m footprint accommodates multiple vehicles while maintaining assembly stability for demanding commercial applications.
Vehicle & Storage Capacity
The 36 square metre interior accommodates two standard vehicles or large commercial equipment with generous clearance. Double-glazed timber doors provide wide access for machinery entry and exit. The 221cm eaves height supports adequate vertical space for vans and small trucks while maintaining weather protection throughout the storage area.
Timber & Construction
Northern European timber forms the structural foundation, delivering enhanced density and weather-protection characteristics subject to specification and maintenance for commercial applications. The 44mm wall thickness incorporates interlocking tongue-and-groove joints that create weather-protected seals without additional sealants. Standard profile double glazing in both doors and windows supports thermal specification and security for equipment storage.
Technical Specifications
External dimensions measure 6x6 metres with a pent roof rising from 221cm eaves to 260cm ridge height. The structure includes 19mm tongue-and-groove roof boards for weather protection. Standard timber joinery provides double-glazed doors and windows. Floor boards are excluded, allowing contractors to specify appropriate foundation systems for their applications.
Customisation Options
Wall thickness upgrades accommodate specific thermal requirements for heated storage applications. Insulation packages integrate with the timber framework for year-round equipment protection. Enhanced glazing specifications include triple-glazing options and security glass. Partition systems create separated storage zones, while veranda extensions provide covered workspace areas for maintenance operations.
Manufacturing & Delivery
The Eurodita factory is dimensioned for 150,000 m³ of timber a year. Freight route and final delivery timing are agreed per order in the written quotation. The Eurodita brand standard terms are EXW from the Eurodita factory. Bespoke modifications integrate directly with our manufacturing processes, supporting consistent quality across standard and customised specifications for trade partners throughout Europe.
Private Label Partnership
Private-label capability allows retailers to market this garage under their own branding with customised documentation and technical specifications. Our design team provides 3D visualisation services for customer presentations and planning applications. Showroom display programmes include sample materials and technical training, supporting dealers with professional product knowledge and sales tools.
What should dealers confirm before quoting Double Log Garage 6×6, Pent, 44mm?
Eurodita supplies Double Log Garage 6×6, Pent, 44mm as a private-label B2B garage or carport product with a 6x6m footprint and 44mm Northern European timber wall specification. Before quoting, dealers should confirm the quote stage package, vehicle-clearance needs, door/opening layout, roof and floor package, foundation interface, treatment or finish route, unloading access, EXW release or freight route from the Eurodita factory, private-label documentation, and local-authority planning or site-use review requirements.
Warranty & Support
Product, order and after-sales conditions are confirmed in writing for each project in the quotation, order confirmation and applicable product documentation. Please contact Eurodita for the documentation relevant to your confirmed order. Pressure treatment protects against moisture and insect damage throughout the warranty period. Comprehensive assembly documentation includes technical drawings and component schedules. Our technical support team provides guidance on foundation requirements and installation procedures for contractors and installers.
