Mobile Log Home 1 Bed 14x6m
Technical data sheet
Specification recorded for Mobile Log Home 1 Bed 14x6m. Dimensions are the building's external dimensions. A row appears only where a figure is recorded for this model.
| Building | |
|---|---|
| External dimensions | 14 x 6 m |
| External footprint area | 84 m² |
| Eaves height | 220 cm |
| Ridge height | 285 cm |
| Base | External footprint 14 x 6 m. Base type and size are confirmed for the specific model and site. |
| Structure | |
| Wall profile options | 70 x 130 mm, 88 x 260 mm, 135 x 260 mm, 180 x 260 mm or 220 x 260 mm glulam, chosen per project and budget |
| Corner system | Dovetail corner system available on the 88 to 220 mm glulam profiles, not on 70 x 130 mm |
| Construction | Interlocking tongue and groove joints |
| Timber | Glued-laminated timber |
| Storm brace and anchor set | Included |
| Floor | |
| Floor bearers | 13.5 x 13.5 cm glulam |
| Floor boards | 28 mm |
| Roof | |
| Roof form | Apex |
| Roof boards | 19 mm tongue and groove boards |
| Doors and windows | |
| Doors | Double-Glazed Timber Joinery, Insulated Profile |
| Windows | Double-Glazed Timber Joinery, Insulated Profile |
| Scope of these figures | |
| Insulation | Eurodita supplies the timber structure prepared for insulation where required, not the insulation material. |
| Performance | These dimensions establish no thermal, fire, structural or certification performance. |
Add-ons & Customisation
Options for this model (branding, wall thickness, openings, insulation preparation, partitions, veranda) are listed on What is in a Eurodita kit and confirmed per order.
Need this in a different size?
This model is supplied as a 14 x 6 m footprint. If your customer needs a different layout, send a drawing. Eurodita will confirm whether the qualified bespoke route and factory scope fit the exact project. Partner branding is agreed per order.
- 1 Send a drawing A hand sketch can start the review. Mark known window and door positions, wall thickness and heights; Eurodita confirms any missing technical inputs.
- 2 Confirm the quotation scope If the enquiry fits, pricing and any CAD/3D or technical material are prepared to the agreed scope.
- 3 Review the agreed scope Revisions follow the quotation and project scope until written sign-off.
CAD/3D quotation material is prepared to the qualified project scope. Availability and timing are confirmed during qualification. Partner branding is applied where agreed; required manufacturer, legal and traceability information is retained.
Send a bespoke briefDimensions, wall thickness and opening positions are confirmed per project at quote stage. Bespoke production timing is confirmed at quotation stage. See published projects for built examples with dimensions and drawings, or review the rest of the mobile log homes range.
About This Mobile Log Home 1 Bed 14x6m
Product Overview
This one-bedroom mobile log home has a 14x6m external footprint (84m²) configured around UK Caravan Sites Act 1968 (as amended by SI 2006/2374) dimensional criteria for dealer and local-authority review. This one-bedroom layout supports holiday-park, managed-site and accommodation-project briefs where additional living space is part of the specification review. The full-height 294cm ridge construction provides generous interior volume while keeping transport planning subject to the confirmed route and project documentation.
Layout and Configuration
At 14x6m, the internal layout provides a generously proportioned open-plan living area alongside a fully enclosed bedroom and separate bathroom. The additional floor area permits dedicated hallway circulation, larger kitchen preparation zones, and supplementary storage capacity beyond minimum requirements. The standard 220cm eaves height ensures comfortable headroom throughout, with the apex roof profile creating additional storage opportunities above partition walls.
Timber and Construction
Northern European timber forms 88mm thick exterior walls using precision-machined tongue-and-groove profiles for assembly integrity and weather-exposure review. Double-glazed timber joinery incorporates insulated door and window frames throughout the structure. The compact building envelope benefits from efficient material utilisation, with shorter wall spans reducing the requirement for intermediate bracing. Assembly integrity is maintained through continuous interlocking profiles that support assembly review across the compact perimeter.
Floor and Roof
Pressure-treated 13.5×13.5cm glulam floor bearers support 28mm tongue-and-groove floor boarding specified for project-use requirements across the full 84m² floor plate. Roof construction utilises 19mm tongue-and-groove boards providing a solid substrate for insulation and selected roof covering systems. Standard bearer spacing provides reliable support across the compact floor area. The roof structure spans the narrow width efficiently, with integrated storm bracing systems securing the assembly against uplift forces.
Customisation Options
Glulam wall-profile and insulation options are confirmed at quote stage according to the project brief, destination climate and local-authority review route. Additional insulation packages, triple-glazing options, and alternative door and window configurations are specified for the destination climate and local project review route. One-bedroom configurations benefit from kitchenette specification options, space-efficient integrated storage solutions, and compact bathroom layout alternatives. Fold-away and multi-functional furniture provisions can be incorporated into the internal design to maximise the usable floor area.
Manufacturing and Delivery
Production at the Eurodita facility in Lithuania uses Hundegger CNC cutting systems and Nardi kiln-drying technology for Northern European timber components. Production and logistics timing is confirmed per order according to specification, order volume, factory planning, transport route and site-access needs. The compact one-bedroom format enables efficient single-vehicle delivery, reducing transport costs and simplifying site logistics. Assembly time depends on the site, the base and the crew; Eurodita publishes no assembly duration.
Private Label Partnership
Private-label manufacturing enables dealers to supply this mobile home under their own brand identity with no visible Eurodita branding on the delivered product. Partner support includes customised assembly documentation, branded customer communications, and 3D visualisation tools for showroom and catalogue presentation. Flexible order volumes accommodate both individual project requirements and ongoing supply agreements for holiday-park, managed-site and accommodation operators.
Warranty and Support
Product, order and after-sales conditions are confirmed in writing for each project in the quotation, order confirmation and applicable product documentation. Please contact Eurodita for the documentation relevant to your confirmed order. Technical documentation includes detailed assembly drawings, hardware schedules, foundation guidance, and ongoing maintenance recommendations. The Eurodita sales team handles specification support, project quotations and after-sales technical questions. One-bedroom mobile homes provide an accessible entry point for dealers building a mobile timber accommodation portfolio with clear specification and documentation needs.
What should dealers verify before quoting Mobile Log Home 1 Bed 14x6m?
Eurodita manufactures Mobile Log Home 1 Bed 14x6m as an 88mm engineered glulam mobile log home for private-label B2B partners. Before quoting, dealers should confirm the project route against Eurodita Mobile Log Homes B2B range, the BS 3632 project-review route where relevant, site-licence or local-authority checks, layout changes, services, documentation scope and EXW Eurodita factory logistics. Final specification suitability, siting route and approval remain with the dealer, site operator, local authority or appointed assessor.
